4 Port Fiber Optic Circulator

4 Port Fiber Optic Circulator

PHX's 4-port fiber Circulators are available in single-mode fiber versions. These fiber circulators are ideal for advanced communication systems and fiber sensing applications.
Get Quote Now
4 Port Fiber Optic Circulator

Features of 4 Port Fiber Optic Circulator

1. Low insertion loss, High isolation, High stability and reliability, High extinction ratio.

2. Comply with international RoHS standards, GR-1209 and GR-1221.

3. Single-mode optical fiber.

Specifications of Port Fiber Optic Circulator

Specifications

Unit

Parameter

Center wavelength

nm

1310 or 1550

1064

Operating wavelength broadband

nm

±30

±5

Typical insertion loss 23℃

dB

1.0

2.2

Maximum insertion loss 23℃

dB

1.2

2.5

Typical peak isolation 23℃

dB

50

30

Minimum isolation 23℃

dB

40

25

Typical extinction ratio 23℃

dB

0.15

20

Minimum crosstalk

dB

50


Minimum return loss

dB

50


Maximum transmission power(CW)

mW

300


Maximum tension

N

5


Optical fiber type

-

Corning SMF-28e or Hi-1060 fiber

Working temperature

-5~+70

Storage temperature

-40~+85

The above does not include connection head insertion loss



Package Size of Port Fiber Optic Circulator

Port Fiber Optic Circulator

SMCIR-1111-23456-777

1111

-Center Wavelength:

1550=1550nm, 1310=1310nm

2

-Port Type:

3=3 Port, 4=4 Port

5

-Pigtail Type:

0=250μm bare fiber, 1=900μm loose tube

6

-Fiber Length:

0=0.8m, 1=1m

777

-Connector Type:

0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, 4=LC/UPC, 5=LC/APC
