Fused WDM Module (1310/1550)

Fused WDM Module (1310/1550)

PHX's fused WDM can provide 1310 / 1550, 1x2, 2x2 combination or separation of different wavelengths of light. Fused WDM modules have very low insertion loss, low polarization dependence, high isolation and excellent environmental stability. These Fused WDM modules have been widely used in cable TV, WDM networking, optical fiber sensor, optical fiber communication, and optical fiber instrument.
Get Quote Now
Fused WDM Module (1310/1550)

Characteristics of Fused WDM Module (1310/1550)

1. Low insertion loss

2. Low polarization dependent loss

3. High isolation

4. High stability and reliability

Parameters of Fused WDM Module (1310/1550)

Parameter

WA

WB

WC

Grade

P

A

P

P

Insertion Loss (Max) (dB)

0.3

0.4

0.7

1.2

lsolation (Min.) (dB)

≥17

≥16

≥34

≥45

PDL (dB)

≤0.05

<0.10

<0.10

<0.15

Operating Wavelength (nm)

1295 ~ 1325/1528 ~ 1565

Return Loss (Min.) (dB)

≥55

Directivity (dB)

≥55

Operating Temperature (℃)

-10~+70

Storage Temperature (℃)

-40~+85

Fiber Pigtail Length (m)

1 m or custom length

Fiber Type

Corning singlemode SMF-28

Port Configuration

1x2 or 2x2

Package Dimension

F,G,H,1,3

1,2

1
