Mini Size Coupler (MSC)

Mini Size Coupler (MSC)

PHXFIBER also builds mini size couplers, the smallest package (steel tube) dimension isФ2.4x25mm. They are usually used in Mini size EDFA, transmitter/ receiver modules. They have various coupling ratios, such as 1/99, 2/98, 3/97, 10/90 and 50/50 etc. ​
Get Quote Now
Mini Size Coupler (MSC)

Applications of Mini Size Coupler (MSC)

1. Mini size EDFA

2. Testing instrument

3. Optical communication systems

4.  Mini size transmitter/receiver module


Specifications of Mini Size Coupler (MSC)


Mini Size Standard Coupler (MSC)

Operating wavelength (nm)

1310 or 1550 for single-window type, 1310&1550 for dual window type**

Operating bandwidth (nm)

±15, ±40

Port configuration

1x2 or 2x2

Grade

P

A

P

A

Typical excess loss (dB)

0.10

0.15

0.15

0.25

Insertion Loss (dB)

50/50

≤3.5

≤3.7

≤3.6

≤3.7

40/60

≤4.5/2.7

≤4.8/2.9

≤4.6/2.8

≤4.9/3.0

30/70

≤5.8/2.0

≤6.1/2.1

≤5.9/2.1

≤6.3/2.2

20/80

≤7.7/1.25

≤8.0/1.3

≤7.8/1.3

≤8.2/1.4

10/90

9.35~11.15/≤0.7

9.15~11.35/≤0.85

9.5~11.3/≤0.75

9.3~11.50/≤0.85

5/95

12.15~14.35/≤0.45

11.9~14.6/≤0.55

12.3~14.5/≤0.5

12.05~14.75/≤0.55

3/97

14.2~16.7/≤0.35

13.9~17.0/≤0.45

14.35~16.85/≤0.4

14.05~17.15/≤0.45

2/98

15.85~18.5/≤0.3

15.5~19.0/≤0.35

16.0~18.8/≤0.35

15.65~19.15/≤0.4

1/99

18.7~21.15/≤0.25

18.3~22.2/≤0.3

18.85~21.8/≤0.3

18.45~22.35/≤0.35

PDL (dB)

≤0.10

≤0.15

≤0.10

≤0.15

Directivity (dB)

≥50

Operating temperature (℃)

-40  ~  +85

Package Dimension (Steel tube)

Ф3.0×30mm; Ф2.4×30mm; Ф2.4×25mm

*The above specification is without a connector.

**Other specifications can be made on customer request.



Ordering Information of Mini Size Coupler (MSC)

MSC

X

XXX

XXXX

XX/XX

X

X

XXX

XX/XX


Grade

Port number

Operating Wavelength

Coupling Ratio

Pigtail Type

Encapsulation steel tube

Fiber Length

Connector


P=Perfect

1×2

1310=1310

01/99

0=250um

2.4/3.0×30

1m

FC/UPC


A=Grade A

2×2

1550=1550

02/98



1.5m

FC/APC


X=customized



03/97

4=others


2m

SC/UPC
