SC Auto Shutter Connector And Adapter

SC Auto Shutter Connector And Adapter

SC fast/quick connector features low insertion loss and added Loss, High stability, high reliability, the height of attenuation, high back loss, small volume, lightweight. Sc adapters with shutter opens and close automatically. SC Auto-door connector can be used with a regular SC adapter and offers the highest level of dust and laser protection available. The design of sc fast connector and sc adapters with shutter conforms to human engineering, which is easy to handle and suitable for optical cable diameter:2.0mm,3.0mm. Meets with RoHS and reach.
Get Quote Now
SC Auto Shutter Connector And Adapter

Product Parameters of SC Auto Shutter Connector and Adapter

Type

Parameter

SM-UPC

SM-APC

MM-UPC

Typical

Max

Typical

Max

Typical

Max

Insertion Loss

≤0.10dB

≤0.30dB

≤0.15dB

≤0.30dB

≤0.05dB

≤0.30dB

Return Loss

≥50dB

≥60dB

≥30dB

Durability

500 times a plug

Operation Temperature

-40 to + 85℃



Application of SC Auto Shutter Connector and Adapter

1. Optical fiber communication systems engineering.

2. Fiber optic data communication network.

3. Fiber CATV, FTTH engineering.

4. Other optical technology tests.


Features of SC Auto Shutter Connector and Adapter

1. Low insertion loss and added loss.

2. High stability, high reliability, height of attenuation.

3. High back loss, small volume, light weight.

4. Shutters open and close automatically.

5. SC Auto-door connector can be used with a regular SC adapter.

6. Offers the highest level of dust and laser protection available.

7. Connector design conforms to human engineering, easy to handle.

8. Suitable for optical cable diameter:2.0mm,3.0mm.

9. Meets with RoHS and reach.
